Tobii¶

Platforms:

Windows 7 / 10
Linux
macOS

Required Python Version:

Python 3.6 +

Supported Models:

Tobii Pro eye tracker models that can use the tobii_research Python package. For a complete list please visit Tobii support.

Additional Software Requirements¶

To use the ioHub interface for Tobii, the Tobi Pro SDK must be installed in your Python environment. If a recent standalone installation of |PsychoPy|, this package should already be included.

To install tobii-research type:

pip install tobii-research

EyeTracker Class¶

class psychopy.iohub.devices.eyetracker.hw.tobii.EyeTracker[source]¶

To start iohub with a Tobii eye tracker device, add the Tobii device to the dictionary passed to launchHubServer or the experiment’s iohub_config.yaml:

eyetracker.hw.tobii.EyeTracker

Examples

Start ioHub with a Tobii device and run tracker calibration:

from psychopy.iohub import launchHubServer
from psychopy.core import getTime, wait

iohub_config = {'eyetracker.hw.tobii.EyeTracker':
    {'name': 'tracker', 'runtime_settings': {'sampling_rate': 120}}}

io = launchHubServer(**iohub_config)

# Get the eye tracker device.
tracker = io.devices.tracker

# run eyetracker calibration
r = tracker.runSetupProcedure()

Print all eye tracker events received for 2 seconds:

# Check for and print any eye tracker events received...
tracker.setRecordingState(True)

stime = getTime()
while getTime()-stime < 2.0:
    for e in tracker.getEvents():
        print(e)

Print current eye position for 5 seconds:

# Check for and print current eye position every 100 msec.
stime = getTime()
while getTime()-stime < 5.0:
    print(tracker.getPosition())
    wait(0.1)

tracker.setRecordingState(False)

# Stop the ioHub Server
io.quit()

clearEvents(event_type=None, filter_id=None, call_proc_events=True)¶

Clears any DeviceEvents that have occurred since the last call to the device’s getEvents(), or clearEvents() methods.

Note that calling clearEvents() at the device level only clears the given device’s event buffer. The ioHub Process’s Global Event Buffer is unchanged.

Parameters:: None
Returns:: None

enableEventReporting(enabled=True)[source]¶: enableEventReporting is functionally identical to the eye tracker device specific enableEventReporting method.

getConfiguration()¶

Retrieve the configuration settings information used to create the device instance. This will the default settings for the device, found in iohub.devices.<device_name>.default_<device_name>.yaml, updated with any device settings provided via launchHubServer(…).

Changing any values in the returned dictionary has no effect on the device state.

Parameters:: None
Returns:: The dictionary of the device configuration settings used to create the device.
Return type:: (dict)

getEvents(*args, **kwargs)¶

Retrieve any DeviceEvents that have occurred since the last call to the device’s getEvents() or clearEvents() methods.

Note that calling getEvents() at a device level does not change the Global Event Buffer’s contents.

Parameters:

event_type_id (int) – If specified, provides the ioHub DeviceEvent ID for which events
ID (should be returned for. Events that have occurred but do not match the event)
class; (specified are ignored. Event type ID's can be accessed via the EventConstants)
EventConstants. (all available event types are class attributes of)
clearEvents (int) – Can be used to indicate if the events being returned should also be
True (removed from the device event buffer.)
buffer. (being returned. False results in events being left in the device event)
asType (str) – Optional kwarg giving the object type to return events as. Valid values
'namedtuple' (are)

Returns:

New events that the ioHub has received since the last getEvents() or clearEvents() call to the device. Events are ordered by the ioHub time of each event, older event at index 0. The event object type is determined by the asType parameter passed to the method. By default a namedtuple object is returned for each event.

Return type:

(list)

getLastGazePosition()[source]¶

Returns the latest 2D eye gaze position retrieved from the Tobii device. This represents where the eye tracker is reporting each eye gaze vector is intersecting the calibrated surface.

In general, the y or vertical component of each eyes gaze position should be the same value, since in typical user populations the two eyes are yoked vertically when they move. Therefore any difference between the two eyes in the y dimension is likely due to eye tracker error.

Differences between the x, or horizontal component of the gaze position, indicate that the participant is being reported as looking behind or in front of the calibrated plane. When a user is looking at the calibration surface , the x component of the two eyes gaze position should be the same. Differences between the x value for each eye either indicates that the user is not focussing at the calibrated depth, or that there is error in the eye data.

The above remarks are true for any eye tracker in general.

The getLastGazePosition method returns the most recent eye gaze position retrieved from the eye tracker device. This is the position on the calibrated 2D surface that the eye tracker is reporting as the current eye position. The units are in the units in use by the Display device.

If binocular recording is being performed, the average position of both eyes is returned.

If no samples have been received from the eye tracker, or the eye tracker is not currently recording data, None is returned.

Parameters:

None

Returns:

If the eye tracker is not currently recording data or no eye samples have been received.

tuple: Latest (gaze_x,gaze_y) position of the eye(s)

Return type:

None

getLastSample()[source]¶

Returns the latest sample retrieved from the Tobii device. The Tobii system always using the BinocularSample Event type.

Parameters:

None

Returns:

If the eye tracker is not currently recording data.

EyeSample: If the eye tracker is recording in a monocular tracking mode, the latest sample event of this event type is returned.

BinocularEyeSample: If the eye tracker is recording in a binocular tracking mode, the latest sample event of this event type is returned.

Return type:

None

getPosition()¶: See getLastGazePosition().

isRecordingEnabled()[source]¶

isRecordingEnabled returns the recording state from the eye tracking device.

Parameters:: None
Returns:: True == the device is recording data; False == Recording is not occurring
Return type:: bool

runSetupProcedure(calibration_args={})[source]¶: runSetupProcedure performs a calibration routine for the Tobii eye tracking system.

setRecordingState(recording)[source]¶

setRecordingState is used to start or stop the recording of data from the eye tracking device.

Parameters:: recording (bool) – if True, the eye tracker will start recordng available eye data and sending it to the experiment program if data streaming was enabled for the device. If recording == False, then the eye tracker stops recording eye data and streaming it to the experiment.

If the eye tracker is already recording, and setRecordingState(True) is called, the eye tracker will simple continue recording and the method call is a no-op. Likewise if the system has already stopped recording and setRecordingState(False) is called again.

Parameters:: recording (bool) – if True, the eye tracker will start recordng data.; false = stop recording data.
Returns:: the current recording state of the eye tracking device
Return type:: bool

Supported Event Types¶

tobii_research provides real-time access to binocular sample data.

The following fields of the ioHub BinocularEyeSample event are supported:

class psychopy.iohub.devices.eyetracker.BinocularEyeSampleEvent(*args, **kwargs)[source]¶

The BinocularEyeSampleEvent event represents the eye position and eye attribute data collected from one frame or reading of an eye tracker device that is recording both eyes of a participant.

Event Type ID: EventConstants.BINOCULAR_EYE_SAMPLE

Event Type String: ‘BINOCULAR_EYE_SAMPLE’

time¶: time of event, in sec.msec format, using psychopy timebase.

left_gaze_x¶: The horizontal position of the left eye on the computer screen, in Display Coordinate Type Units. Calibration must be done prior to reading (meaningful) gaze data. Uses tobii_research gaze data ‘left_gaze_point_on_display_area’[0] field.

left_gaze_y¶: The vertical position of the left eye on the computer screen, in Display Coordinate Type Units. Calibration must be done prior to reading (meaningful) gaze data. Uses tobii_research gaze data ‘left_gaze_point_on_display_area’[1] field.

left_eye_cam_x¶: The left x eye position in the eye trackers 3D coordinate space. Uses tobii_research gaze data ‘left_gaze_origin_in_trackbox_coordinate_system’[0] field.

left_eye_cam_y¶: The left y eye position in the eye trackers 3D coordinate space. Uses tobii_research gaze data ‘left_gaze_origin_in_trackbox_coordinate_system’[1] field.

left_eye_cam_z¶: The left z eye position in the eye trackers 3D coordinate space. Uses tobii_research gaze data ‘left_gaze_origin_in_trackbox_coordinate_system’[2] field.

left_pupil_measure_1¶: Left eye pupil diameter in mm. Uses tobii_research gaze data ‘left_pupil_diameter’ field.

right_gaze_x¶: The horizontal position of the right eye on the computer screen, in Display Coordinate Type Units. Calibration must be done prior to reading (meaningful) gaze data. Uses tobii_research gaze data ‘right_gaze_point_on_display_area’[0] field.

right_gaze_y¶: The vertical position of the right eye on the computer screen, in Display Coordinate Type Units. Calibration must be done prior to reading (meaningful) gaze data. Uses tobii_research gaze data ‘right_gaze_point_on_display_area’[1] field.

right_eye_cam_x¶: The right x eye position in the eye trackers 3D coordinate space. Uses tobii_research gaze data ‘right_gaze_origin_in_trackbox_coordinate_system’[0] field.

right_eye_cam_y¶: The right y eye position in the eye trackers 3D coordinate space. Uses tobii_research gaze data ‘right_gaze_origin_in_trackbox_coordinate_system’[1] field.

right_eye_cam_z¶: The right z eye position in the eye trackers 3D coordinate space. Uses tobii_research gaze data ‘right_gaze_origin_in_trackbox_coordinate_system’[2] field.

right_pupil_measure_1¶: Right eye pupil diameter in mm. Uses tobii_research gaze data ‘right_pupil_diameter’ field.

status¶: Indicates if eye sample contains ‘valid’ data for left and right eyes. 0 = Eye sample is OK. 2 = Right eye data is likely invalid. 20 = Left eye data is likely invalid. 22 = Eye sample is likely invalid.

Default Device Settings¶

Last Updated: January, 2021
